Intellian TV Antennas
i9P |
i6/i6P |
i6PE |
i4/i4P |
|
Dish Size |
85cm(33.5") |
60cm (23.6") |
60cm (23.6") |
45cm (17.7") |
Radome |
108 x 110 cm |
10 x 72 cm |
10 x 72 cm |
50 x 54 cm |
Weight |
55Kg(121.2 lbs) |
20Kg(44lbs) |
20Kg(44lbs) |
11.6Kg(25.6 lbs) |
Axes |
2 |
2 |
2 |
2 |
Az range |
680 |
680 |
680 |
680 |
El range |
-15 to + 90 |
+5 to +90 |
-15 to +90 |
0 to +90 |
Min EIRP |
44dBW |
47dBW |
47dBW |
49dBW |
Band |
Ku:Dual/Quad |
Ku:Dual/Quad |
Ku:Dual/Quad |
Ku:Dual/Quad |
Power |
9.0 - 30VDC |
9.0 - 30VDC |
9.0 - 30VDC |
9.0 - 30VDC |
Datasheet |
||||
|
Intellian d4 and d6 Ka+Ku (HD+SD) antennas
This is a combination Ku-Band / Ka-Band antenna designed to receive DirecTV High definition and Standard definintion TV on 99W, 101W and 103W.
i3 |
i2 |
i1 |
|
Dish Size |
37cm(14.6") |
33cm (13") |
28cm (11") |
Radome |
43 x 44 cm |
37 x 38 cm |
33 x 30 cm |
Weight |
9Kg(19.8 lbs) |
4.5 Kg (9.5 lbs) |
4.3 Kg (9.4 lbs) |
Axes |
2 |
2 |
2 |
Az range |
680 |
680 |
680 |
El range |
+10 to +80 |
+10 to +80 |
+20 to +80 |
Min EIRP |
50dBW |
51dBW |
52-53dBW |
Band |
Ku:Dual/Quad |
Ku:Dual |
Ku:Dual |
Power |
9.0 - 30VDC |
9.0-30VDC |
10.8-15.6VDC |
Datasheet |
Intellian i9/i9P, i6/i6P, i4/i4P Ku band with Polarization
The P behind the model number indicated auto skew adjustment for linear satellites.
The i6PE has extended elevation range (like the i9P) of -15 degrees to +90 degrees for trackiing in rough weather where the roll of the ship would cause the satellite to drop below zero degrees.
t110 |
t130 |
|
Dish Size |
1.05m(41.3") |
1.25m (49.2") |
Radome |
1.3m x 1.42m |
1.55m x 1.65m |
Weight |
88Kg (194lbs) |
98Kg (216lbs) |
Axes |
3 |
3 |
Az range |
680 |
680 |
El range |
-15 ~ 120 |
-15~120 |
Min EIRP |
42dBW |
40dBW |
Band |
Ku |
Ku |
k4 |
k6 |
|
Dish Size |
45cm (17.7") |
60cm (23.6") |
Radome |
50cm x 54 cm |
70cm x 72cm |
Weight |
11.7Kg (25.8 lbs) |
20Kg (44.1 lbs) |
Axes |
2 |
2 |
Az range |
680 |
680 |
El range |
0 ~ 90 |
5 ~90 |
Band |
Ka |
Ka |
Intellian t110 and t130, 3 axis Ku TV antennas | Intellian d4 and d6 Ka+Ku (HD+SD) antennas | Intellian i9/i9P, i6/i6P, i4/i4P Ku band with Polarization | Intellian i1, i2, i3 Ku Band TV antennas |
Intellian t110 and t130, 3 axis Ku TV antennas
