KNS_SUPER_TRACK_S4

KU-BAND TVRO

사진

Equipped with the state of the art KNS 3 axis servo stabilization system and the built-in GPS,
The S-Series outperforms all other TVRO systems in the market today.

Larger S-Series antennas providing stronger signal acquisitions are available for more efficient performance in any condition.

Standard Features



  • Automatic Satellite Search & Skew Control

  • Accurate Signal Acquisition by KNS’s Distinctive Algorithm

  • Pre-programmed Satellite Database

    Editable 80 satellite data

  • Antenna Control Unit

    DiSEqC 1.2 function

  • CE (EN60945) Satisfied

  • True 3 Axis

  • ABOVE DECK

    Dish Diameter 45cm(18”)
    Antenna Dimension 67cm(D) x 69cm(H)
    Antenna Weight 25 Kg
    Radome Material Plastic
    Frequency 10.75GHz ~ 12.75GHz
    Minimum EIRP 54 dBW
    Operating Platform 3 - Axis
    LNB Quad / Quattro LNB(optional)
    Skew Control Automatic
    Elevation Angle -20˚ to +95˚
    Azimuth Range 640˚
    Cross Angle ± 35˚
    Ship Motion Roll : ±20˚ at 8-12 sec periods
      Pitch : ±10˚ at 6-12 sec periods
      Yaw : ±8˚ at 15-20 sec periods
    Tracking Speed More than 90˚/sec
    Vibration Damper Rubber Damper included
    Temperature -20˚C to +55˚C
    Humidity Up to 100% @ 40˚C
    Antenna Input Power 24V DC, 4.17A

  • BELOW DECK

    ACU Size 253 x 175 x 44 cm
    Gyro Interface NMEA 0183
    Input Power 100 - 240V AC, 50/60Hz, 2.8A
    Output Power 24V DC, 4.17A
    External I/O Mini-USB

  • PACKING

    Size 82 x 82 x 98 cm
    Gross Weight 44Kg
    Packed by Paper Carton

  • WARRANTY INFORMATION

    KNS offers 2-year parts, 1-year onboard labour warranty for the SuperTrack series
